Veritas® Skew Rabbet Plane with PM-V11 Blade - Left Hand

Veritas® Skew Rabbet Plane with PM-V11 Blade - Left Hand

Product Code:
05P45-78

With a blade skewed at a 30 angle to reduce cut resistance and aid in shaving clearance, this plane cuts quickly and quietly, avoiding the set-up, noise and dust associated with power tools.
Corner cuts are clean and accurate. Tear-out on cross-grain work is reduced with a scoring spur that sits ahead of the blade. The 7 3/8" long fence allows a maximum rabbet width of 1 1/2" and is through-drilled to accept a wooden extension. An adjustable shoe controls the rabbet depth to a maximum 3/4" deep.
Supplied with a lapped blade 1/8" thick and just over 1 5/8" wide, with a bevel edge that is about 1 3/4", in A2, O1 or PM-V11 steel. The depth-adjustment mechanism is fast and accurate. Set screws along the side allow repeatable blade positioning. The 9 3/4" long ductile cast iron body is machined with a 45 blade bed and weighs 3 1/2 lb.
The plane is available in left- and right-hand versions. You may need only the version that suits your dominant hand, though they are in fact complementary, since having both lets you accommodate any grain direction. Patented.
A pair of 6" stainless-steel fence rods (2 1/2" longer than the rods supplied with the plane) are available separately.
Made in Canada.

$513.00
$0.00 $513.00
Inc GST
Tax included. Shipping calculated at checkout.
Or from $10/week with
Or pay in 4 interest-free payments of $128.25
Carbatec offers a variety of warranties and return options for selected products. Please refer to the Warranty Documentation provided with your purchased product for full details, inclusions and exclusions. See our Terms Of Service for further information.
Need assistance?
We're Here To Help 9am - 5pm AEST Monday - Friday and 8am - 12pm AEST Saturdays
1800 658 111
Call us
View full details
Product Details

With a blade skewed at a 30° angle to reduce cut resistance and aid in shaving clearance, this plane cuts quickly and quietly, avoiding the set-up, noise and dust associated with power tools.
Corner cuts are clean and accurate. Tear-out on cross-grain work is reduced with a scoring spur that sits ahead of the blade. The 7 3/8" long fence allows a maximum rabbet width of 1 1/2" and is through-drilled to accept a wooden extension. An adjustable shoe controls the rabbet depth to a maximum 3/4" deep.
Supplied with a lapped blade 1/8" thick and just over 1 5/8" wide, with a bevel edge that is about 1 3/4", in A2, O1 or PM-V11 steel. The depth-adjustment mechanism is fast and accurate. Set screws along the side allow repeatable blade positioning. The 9 3/4" long ductile cast iron body is machined with a 45° blade bed and weighs 3 1/2 lb.
The plane is available in left- and right-hand versions. You may need only the version that suits your dominant hand, though they are in fact complementary, since having both lets you accommodate any grain direction. Patented.
A pair of 6" stainless-steel fence rods (2 1/2" longer than the rods supplied with the plane) are available separately.
Made in Canada.
